1210 Large Format Splicing Laser Marking Machine

1. Ultra-large format marking capability
The effective marking range is up to 1200×1000mm, far exceeding the traditional laser marking machine;
It can clamp large-size workpieces once and mark multiple sections continuously, avoiding repeated positioning and improving efficiency.

2. High-precision mechanical splicing marking technology
Adopting platform moving splicing technology, non-optical splicing, more stable and reliable;
The workpiece or laser head moves along the X and Y axes with high precision through servo motors or linear motors to mark the large image in sections;
The system automatically divides the area, and the software controls the splicing and marking sequence to achieve seamless image splicing, and the error is controlled within ±0.05mm;
Splicing has no dislocation, no ghosting, and no missing marks, which is especially suitable for high-precision industrial manufacturing.

3. Flexible platform movement mode
Supports XY dual-axis automatic moving platform, laser head fixed or platform fixed;
The platform movement is fully linked with the marking process, and the software automatically executes in sections;
The laser head can be optionally equipped with a moving structure to meet the needs of efficient production lines.

4. Intelligent marking control software, supporting automation of complex tasks
Equipped with professional laser marking control software (EZCAD2/3), simple operation, and compatible with multiple formats;
The software supports automatic splicing path planning, image coordinate compensation, variable marking, etc.;
Supports visual positioning system, which can automatically identify image position, angle, offset compensation, and achieve higher automation.

5. Supports automation customization and expansion
The platform structure can be customized to a larger size;
The automatic loading and unloading device and fixture positioning system can be expanded to realize assembly line automation;
Optional visual system, code scanning recognition system, and data acquisition system can be used to realize intelligent manufacturing;
Supports complex processes such as marking of special-shaped workpieces and automatic identification of multi-station content marking.

6. Stable structure, suitable for long-term continuous operation
The whole machine adopts high-rigidity welding structure + thick plate platform, which is earthquake-resistant and stable;
Core components (guide rails, screws, light sources) are selected from well-known brands, with long life and high stability;
Suitable for 24-hour continuous working environment.

7. Environmentally friendly and quiet, easy to maintain
Laser marking is a non-contact processing, no consumables, no pollution, low noise;
Low energy consumption, easy maintenance, the service life of the laser can reach 100,000 hours;
The whole machine has been debugged before leaving the factory, and customers do not need additional calibration.
